The checkbox matrix macro allows you quickly setup a table format of checkboxes for multiple questions from which the user can select multiple answers per row.

This type of question is commonly as a form of feedback/review.


  1. Create your Form using the Forms for Confluence macro
  2. Add the Forms - Checkbox Matrix macro to the form
    The configuration screen when adding a Checkbox Matrix macro.
  3. Set a name for the matrix
  4. Set a label for the matrix, this will appear next to the checkbox matrix options
  5. (Optional) Set a description for the group
  6. Define columns and rows for the checkbox matrix option
    1. Set a label
    2. Set a value
    Setting labels and values for the Checkbox Matrix macro.
  7. Save the macro. A graphical placeholder of the macro will be added to the page.
    Example of the placeholder for the macro when viewing in edit mode.
  8. Preview or Save the page to see the final Checkbox Matrix
    Example of the rendered Checkbox Matrix macro.
